1、 Overview of this device:

This machine is suitable for various plastic products, such as computers, mobile phones, MP3 players, electronic dictionaries, CD/VCD/DVD, cordless phones, etc. This machine adopts a variable cam structure and is driven by an imported roller track, allowing the workpiece to move up and down with the motor, ensuring smooth operation and low noise; Equipped with three types of fixtures: 45 degree hardness scratch testing fixture, eraser testing fixture, alcohol testing fixture, and providing two sets of testing platforms that can simultaneously test two different production ports.

2、 Product standards:

This instrument can meet the requirements of testing methods such as ISO, ASTM, GB, JIS, EN, etc

3、 Product application and characteristics:

This machine is a wear-resistant and friction testing machine, which uses motor transmission to move products from wear-resistant samples; Judging by the number of times displayed on indicators or digital displays. Product Description: Wear resistance testing is an extremely important testing item in the comprehensive testing of plastic products. This machine is fixed on the surface of the friction cone with a special rubber or dipped in alcohol with a cotton cloth. After rubbing the surface of plastic products and their accessories under a certain load and frequency, the wear resistance is evaluated. (Mobile phone, battery, mouse, chassis).

1. This machine has the function of adjustable speed and adjustable stroke;

2. It can display the current testing speed and number of tests;

3. Multi functional counter, can preset the number of times to be tested, and automatically shut down after reaching the desired level;

4. Equipped with three types of fixtures: hardness scratch test fixture (pencil), eraser test fixture, and alcohol test fixture

4、 Main technical parameters of the product:

1. Module: 40 * 20mm

2. Specification: Two axis (can be used for both rubber and alcohol friction, and can also be tested for pencil hardness)

3. Testing speed: 10-60 times/minute, adjustable and customizable

4. Test travel: 0-160mm round-trip travel (adjustable)

5. Test frequency: 0-999900 times

6. Action mode: Motor transmission

7. Test load: 3KG

8. Load accuracy: ± 1%

9. Test load: (Weights: 100g, 200g, 300g, 500g, 500g, 1000g each)

10. Maximum load-bearing capacity of the countertop: 3KG

11. Power: 0.5KW

12. Weight: 30Kg

13. Power supply: 1 Å, AC220V, 1.5A
