Measurement software:

Shidi CNC/2.5D is a composite multifunctional measurement software. With years of successful development experience in professional measurement software, the R&D team has perfectly combined non-contact laser measuring heads, contact probe measuring heads, and optical imaging to create a brand new composite measurement software.

Easy to operate and powerful, it combines multiple features such as CAD import comparison, full graphic display, quick click operation, real-time data comparison, diversified report formats, and advanced algorithms. The advanced and accurate algorithms are also guaranteed.

Widely used in industries such as mechanical processing, electronics, automobiles, hardware, molds, precision manufacturing, plastic and rubber products, optoelectronics, mobile phones, PCB boards, electronic components, semiconductors, touch screens, LCD panels, medical equipment, cutting tools, bearings, terminals, etc

Basic Function Introduction:

1. Complete measurement functions for geometric dimensions (points, lines, surfaces, circles, spheres, cylinders, arcs, cones), positional tolerances (straightness, flatness, true roundness, true sphericity, cylindricity, positional tolerance, parallelism, perpendicularity).

2. Combination element measurement, such as angle, distance between centers, tangent line, distance between two lines, centerline, center point, vertical distance, angle bisector, intersection point of two lines, etc

3. Measurement of form and position errors, such as centrality, roundness, straightness, parallelism, etc

4. Powerful mathematical operation analysis

5. The image is directly displayed, observed, measured, and stored on a computer screen

6. Using imaging tools can quickly perform 2D contour boundary point scanning

7. Graphical display of measured workpieces, graphics can be saved and printed, and can be converted to TXT, WORD, EXCEL, and AUTOCAD file formats

8. Provide tolerance analysis for effective quality control inspection

9. The objectification of workpieces can directly perform geometric basic operations on objects

10. Compatible with WIN7 and WIN10 operating systems

Advanced Function Introduction:

11. Autofocus

12. Automatic image capture, easy operation, and high measurement accuracy

13. IUI function to complete operations in as little time as possible

14. AUTOCAD file reading and graphic comparison

15. Fully automatic concentric doubling, the same workpiece can be measured at different magnifications (optional)

16. No need to straighten the work, with coordinate conversion function, high measurement efficiency

17. Program self-learning, array replication and other functions to achieve large-scale automatic detection and improve work efficiency.

18. SPC function

19. Static measurement function.

20. Image capture function for workpiece measurement images.

21. Provide powerful linear and nonlinear compensation functions to ensure higher machine accuracy.

Work does not need to be aligned, with coordinate conversion function and high measurement efficiency
