2. Main functions:

Mainly suitable for testing metal and non-metallic materials, such as rubber, plastic, wires and cables, fiber optic cables, safety belts, leather belt composite materials, plastic profiles, waterproof rolls, steel pipes, copper materials, profiles, spring steel, bearing steel, stainless steel (and other high hardness steels), castings, steel plates, steel strips, and non-ferrous metal wires Multiple tests such as two-point extension (additional extensometer required)

This machine adopts an electromechanical integrated design, mainly composed of force sensors, transmitters, microprocessors, load driving mechanisms, computers, and color inkjet printers. It has a wide and accurate loading speed and force measurement range, and has high accuracy and sensitivity in measuring and controlling loads and displacements. It can also perform automatic control experiments for constant speed loading and displacement. The floor standing model fully considers the principles of modern industrial design and ergonomics in its design and painting.

3. Main features:

We use imported photoelectric encoders for displacement measurement, and the controller adopts an embedded single-chip microcomputer structure with powerful measurement and control software built-in, integrating measurement, control, calculation, and storage functions. It has the function of automatically calculating stress, elongation (with the addition of an extensometer), tensile strength, and elastic modulus, and automatically statistics the results; Automatically record the force value or elongation at the maximum point, fracture point, and specified point; Using computers to dynamically display the experimental process and curves, and processing data. After the experiment, the curve can be enlarged, analyzed and edited through a graphics processing module, and reports can be printed. The product performance reaches the international advanced level.

4. Technical parameters:

Host size

900 * 600 * 2000mm (length * width * height)

Maximum load

Self selection within 1000020000kg

Accuracy level

Level 1

source

220V/50HZ

power

4.4KW (standard with different power motors according to different force requirements)

Effective force measurement range

0.01-500mm/min

Force measurement accuracy

Within ± 1% of the indicated value

Load sensor

Basic configuration: One tension and compression sensor (maximum load)

Extended configuration: can be equipped with multiple sensors

Effective test width

400mm (can be widened according to customer requirements)

Effective stretching space

800mm (can be raised according to customer requirements)

Test speed range

0.01-500mm/min

Test bench safety device

Electronic limit protection

Test bench lifting device

Automatic control of both fast and slow speeds, can be clicked

Test bench return function

There are two options: manual or automatic, and after the test is completed, either automatic or manual will return to the initial position of the test at the highest speed

Overload protection

Exceeding maximum load by 10%, machine automatically protects

Fixture configuration

A set of stretching fixtures

dynamic system

Servo motor high-precision ball screw

Host weight

(Approximately) 600 kg
